Product no. M-2790

Container 81.000 / 32.000 liters made of V2A isolated, used, standing

EUR 38.200,00

add. 19 % VAT excl. shipping costs


Volume approx. 113,000.00 litres



Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 81.000 / 32.000 liters made of V2A isolated, used consists of the material 1.4301(AISI304) V2A. The volume is approx. 113,000.00 litres. The diameter inside includes 3,750 mm.  Container 81.000 / 32.000 liters made of V2A isolated, used was last used in the following area: Foodstuffs. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage, Mixing,

General

  • Volume approx.

  • 113.000,00 litres

  • Chamber volume 1

  • 81000 litres

  • Chamber volume 2

  • 32000 litres

  • divided into chambers

  • 2 litres

  • Structure

  • Standing

  • Year of manufacture

  • 1995

  • Manufacturer

  • Thrun

  • Condition

  • Used

Dimensions approx.

  • Internal diameter

  • 3.750 mm

  • External diameter

  • 3.870 mm

  • Cyl. height

  • 11.700 mm

  • Total height

  • 13.000 mm

Design

  • Weight approx.

  • 9.000,00 kg

  • Weight per unit volume approx.

  • 1.000,00 kg/m³

  • Insulation

  • yes

  • Insulated area

  • Shell and head

  • Insulation cladding

  • Fully welded stainless steel

  • Interior surface

  • Smoothed

  • Exterior surface

  • Smoothed

  • Floor type

  • Conical bottom

  • Head design

  • Conical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

Agitator

  • Agitator quantity

  • 2 (piece)

  • Agitator type

  • Propeller

  • Note on agitator

  • jede Kammer ist mit 1 Rührwerk ausgestattet

  • Agitator position

  • At bottom at the side in shell

Fixtures and fittings

  • Manway position

  • In shell

  • Outlet nozzle

  • 80

  • Cleaning/CIP nozzle

  • in head

  • Fixtures and fittings

  • Lifting lugs

  • Additional fixtures and fittings

  • Ladder

  • Air vent

Technical documentation

  • Technical documentation

  • Designation

  • None

Other

  • Last usage

  • Foodstuffs

This product is suitable for use as:

Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Mixing tank,

Agriculture: Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Mixing tank,

Chemistry and pharmaceuticals : Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Mixing tank,
