Product no. M-1836

Container 40.000 liters made of V2A, used, isolated, standing

EUR 23.100,00

add. 19 % VAT excl. shipping costs

Volume approx. 40,000.00 litres

» Send product request » Product data sheet (PDF)

Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 40.000 liters made of V2A, used, isolated consists of the material 1.4301(AISI304) V2A. The volume is approx. 40,000.00 litres.  Container 40.000 liters made of V2A, used, isolated was last used in the following area: Foodstuffs. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage, Hot water, Mixing,

General

  • Volume approx.

  • 40.000,00 litres

  • Structure

  • Standing

  • Manufacturer

  • Alfa-Laval

  • Condition

  • Used

Dimensions approx.

  • External diameter

  • 3.050 mm

  • Cyl. height

  • 6.000 mm

  • Total height

  • 8.300 mm

  • Wall thickness of product chamber head

  • 4,5 mm

  • Wall thickness of product chamber shell

  • 2,5 mm

  • Wall thickness of product chamber floor

  • 3 mm

Design

  • Weight approx.

  • 12.000,00 kg

  • Insulation

  • yes

  • Insulated area

  • Shell and head

  • Insulation cladding

  • Fully welded stainless steel

  • Interior surface

  • Smoothed

  • Exterior surface

  • Smoothed

  • Floor type

  • Conical bottom

  • Head design

  • Conical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

Agitator

  • Agitator quantity

  • 1 (piece)

  • Agitator type

  • Paddle agitator

  • Agitator position

  • Head off-centre

  • Agitator manufacturer

  • Stelzer Typ DRGH 6S

Supports

  • Supports

  • Concrete support skirt

  • Number of feet

  • 1 (piece)

Fixtures and fittings

  • Manway 1 size

  • 410x510 DN mm

  • Manway position

  • In shell

  • Outlet nozzle

  • 100

  • Cleaning/CIP nozzle

  • in head

  • Fixtures and fittings

  • Lifting lugs

  • Additional fixtures and fittings

  • Air vent

  • Nameplate

Other

  • Last usage

  • Foodstuffs

This product is suitable for use as:

Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Syrup tank, Molasses tank/liquid sugar tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Mixing tank, CIP tank, Thermal buffer, Cold water tank,

Agriculture: Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, CIP tank,

Chemistry and pharmaceuticals : Chemical tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Mixing tank, Pressure tank, CIP tank, Cold water tank,
