Product no. M-1794

Container 11.000 liters made of V4A single-walled, used, standing

EUR 4.800,00

add. 19 % VAT excl. shipping costs


Volume approx. 11,000.00 litres



Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 11.000 liters made of V4A single-walled, used consists of the material 1.4571(AISI316) V4A. The volume is approx. 11,000.00 litres.  Container 11.000 liters made of V4A single-walled, used was last used in the following area: Chemistry. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage,

General

  • Volume approx.

  • 11.000,00 litres

  • Structure

  • Standing

  • Condition

  • Used

Dimensions approx.

  • External diameter

  • 2.000 mm

  • Cyl. height

  • 3.430 mm

  • Total height

  • 3.850 mm

Design

  • Weight approx.

  • 800,00 kg

  • Weight per unit volume approx.

  • 1.000,00 kg/m³

  • Insulation

  • no

  • Interior surface

  • Smoothed

  • Exterior surface

  • Smoothed

  • Floor type

  • Flat bottom with slope towards outlet

  • Head design

  • Conical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

Supports

  • Supports

  • Stainless steel support skirt

  • Number of feet

  • 1 (piece)

Fixtures and fittings

  • Manway position

  • In shell

  • Nozzles/connectors in head

  • 3xDN100 1xDN125 (piece)

  • Outlet nozzle

  • 100

  • Fixtures and fittings

  • Lifting lugs

Technical documentation

  • Technical documentation

  • None

Other

  • Last usage

  • Chemistry

This product is suitable for use as:

Foodstuffs:

Agriculture: Storage tank, Buffer tank, Pre-buffer tank, Settling tank,

Chemistry and pharmaceuticals : Storage tank, Buffer tank, Pre-buffer tank, Settling tank,
