Product no. M-1817

Container 32.500 liters made of V2A, used, single-walled, standing

EUR 15.800,00

add. 19 % VAT excl. shipping costs


Volume approx. 32,500.00 litres



Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 32.500 liters made of V2A, used, single-walled consists of the material 1.4301(AISI304) V2A. The volume is approx. 32,500.00 litres.  Container 32.500 liters made of V2A, used, single-walled was last used in the following area: Foodstuffs. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage, Cleaning/CIP,

General

  • Volume approx.

  • 32.500,00 litres

  • Structure

  • Standing

  • Year of manufacture

  • 2000

  • Manufacturer

  • Möschle

  • Condition

  • Used

Dimensions approx.

  • External diameter

  • 3.100 mm

  • Cyl. height

  • 4.300 mm

  • Foot height

  • 700 mm

  • Total height

  • 5.800 mm

Design

  • Interior surface

  • Smoothed

  • Exterior surface

  • Marbled

  • Floor type

  • Conical bottom

  • Head design

  • Conical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

Supports

  • Supports

  • Stainless steel feet

  • Number of feet

  • 6 (piece)

Fixtures and fittings

  • Manway 1 size

  • 340x440 DN mm

  • Manway 2 size

  • 600 DN mm

  • Manway position

  • In floor

  • Nozzle connector

  • Screw thread

  • Nozzles/connectors in head

  • 1xDN 50 (piece)

  • Outlet nozzle

  • 90

  • Fixtures and fittings

  • Lifting lugs

  • Fill level pipes

Technical documentation

  • Technical documentation

  • None

Other

  • Note

  • 1 Fuß leicht eingebeult!

  • Last usage

  • Foodstuffs

This product is suitable for use as:

Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Syrup tank, Molasses tank/liquid sugar tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, CIP tank,

Agriculture: Slurry tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, CIP tank,

Chemistry and pharmaceuticals : Chemical tank, Storage tank, Acid tank, Lye tank, Reactor tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, CIP tank, Cold water tank,
