Product no. M-1404

Container 15.000 liters made of V2A, used, isolated, standing

EUR 9.800,00

add. 19 % VAT excl. shipping costs


Volume approx. 15,000.00 litres



Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 15.000 liters made of V2A, used, isolated consists of the material 1.4301(AISI304) V2A. The volume is approx. 15,000.00 litres. The diameter inside includes 2,600 mm.  Container 15.000 liters made of V2A, used, isolated was last used in the following area: Foodstuffs. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage, Hot water, Cleaning/CIP,

General

  • Volume approx.

  • 15.000,00 litres

  • Structure

  • Standing

  • Year of manufacture

  • 1993

  • Manufacturer

  • Holvrieka

  • Condition

  • Used

Dimensions approx.

  • Internal diameter

  • 2.600 mm

  • External diameter

  • 2.720 mm

  • Cyl. height

  • 3.000 mm

  • Foot height

  • 1.900 mm

  • Outlet height

  • 1.390 mm

  • Total height

  • 5.400 mm

Design

  • Weight approx.

  • 2.000,00 kg

  • Insulation

  • yes

  • Insulated area

  • Shell and floor

  • Insulation cladding

  • Fully welded stainless steel

  • Interior surface

  • Smoothed

  • Exterior surface

  • Smoothed

  • Floor type

  • Conical bottom

  • Head design

  • Conical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

Supports

  • Supports

  • Stainless steel feet

  • Number of feet

  • 4 (piece)

Fixtures and fittings

  • Manway position

  • In head

  • Nozzles/connectors in head

  • 1xDN 100 (piece)

  • Nozzles/connectors in floor

  • 1xDN 80 (piece)

  • Cleaning/CIP nozzle

  • in head

  • Additional fixtures and fittings

  • Flow rectifier

Technical documentation

  • Technical documentation

  • None

Other

  • Last usage

  • Foodstuffs

This product is suitable for use as:

Foodstuffs: Foodstuffs tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, CIP tank, Hot water tank, Thermal buffer, Cold water tank,

Agriculture: Substrate tank, Rainwater tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, CIP tank,

Chemistry and pharmaceuticals : Chemical tank, Storage tank, Acid tank, Lye tank, Buffer tank, Pre-buffer tank, Settling tank, CIP tank, Cold water tank,
