Product no. M-1067

Container 125.000 liters made of V2A, isolated, standing

EUR 27.900,00

add. 19 % VAT excl. shipping costs


Volume approx. 125,000.00 litres



Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 125.000 liters made of V2A, isolated consists of the material 1.4301(AISI304) V2A. The volume is approx. 125,000.00 litres.  Container 125.000 liters made of V2A, isolated was last used in the following area: Foodstuffs. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage, Hot water, Mixing,

General

  • Volume approx.

  • 125.000,00 litres

  • Structure

  • Standing

  • Year of manufacture

  • 1990

  • Condition

  • Used

Dimensions approx.

  • External diameter

  • 3.900 mm

  • Cyl. height

  • 11.000 mm

  • Foot height

  • 300 mm

  • Total height

  • 12.800 mm

Design

  • Weight approx.

  • 25.000,00 kg

  • Weight per unit volume approx.

  • 1.000,00 kg/m³

  • Insulation

  • yes

  • Insulated area

  • Shell and head

  • Insulation cladding

  • Trapezoidal steel sheet

  • Interior surface

  • Smoothed

  • Exterior surface

  • Lacquered

  • Floor type

  • Inverted bottom with slope towards outlet

  • Head design

  • Conical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

Agitator

  • Agitator quantity

  • 1 (piece)

  • Agitator type

  • Propeller

  • Agitator position

  • At bottom at the side in shell

Supports

  • Supports

  • Concrete support skirt

Fixtures and fittings

  • Manway position

  • In shell

  • Outlet nozzle

  • 65

  • Cleaning/CIP nozzle

  • in head

  • Fixtures and fittings

  • Lifting lugs

  • Additional fixtures and fittings

  • Air vent

Technical documentation

  • Technical documentation

  • None

Other

  • Note

  • leichte Druckstellen in der Isolierverkleidung

  • Last usage

  • Foodstuffs

This product is suitable for use as:

Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Syrup tank, Molasses tank/liquid sugar tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, CIP tank, Hot water tank, Thermal buffer, Cold water tank,

Agriculture: Substrate tank, Rainwater tank, Slurry tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, CIP tank, Hot water tank,

Chemistry and pharmaceuticals : Chemical tank, Storage tank, Acid tank, Lye tank, Chemical tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, CIP tank, Hot water tank, Thermal buffer, Cold water tank,
