Product no. M-1276
Container 11.400 liters made of V2A, used, single-walled, standing
EUR 6.300,00
add. 19 % VAT excl. shipping costs
Volume approx. 11,400.00 litres
Product description
Container 11.400 liters made of V2A, used, single-walled consists of the material 1.4301(AISI304) V2A. The volume is approx. 11,400.00 litres. Container 11.400 liters made of V2A, used, single-walled was last used in the following area: Foodstuffs. Delivery can take place worldwide.
This product is suitable for the following applications:
Storage, Cleaning/CIP,General
Volume approx.
11.400,00 litres
Structure
Standing
Condition
Used
Dimensions approx.
External diameter
2.200 mm
Cyl. height
2.500 mm
Foot height
550 mm
Total height
3.450 mm
Wall thickness of product chamber head
2,3 mm
Wall thickness of product chamber shell
2,3 mm
Wall thickness of product chamber floor
2,6 mm
Design
Weight approx.
800,00 kg
Weight per unit volume approx.
1.000,00 kg/m³
Interior surface
Smoothed
Exterior surface
Smoothed
Floor type
Torispherical bottom
Head design
Torispherical bottom
Supports
Supports
Stainless steel feet
Number of feet
4 (piece)
Fixtures and fittings
Manway position
In shell
Nozzle connector
Screw thread
Nozzles/connectors in shell
1 (piece)
Nozzles/connectors in head
1 (piece)
Outlet nozzle
65
Fixtures and fittings
Fill level pipes
Additional fixtures and fittings
Ladder stay
Drain port
Technical documentation
Technical documentation
None
Other
Last usage
Foodstuffs
This product is suitable for use as:
Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Syrup tank, Molasses tank/liquid sugar tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, CIP tank, Cold water tank,
Agriculture: Substrate tank, Rainwater tank, Slurry tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, CIP tank,
Chemistry and pharmaceuticals : Chemical tank, Storage tank, Acid tank, Lye tank, Buffer tank, Pre-buffer tank, Settling tank, CIP tank, Cold water tank,
