Product no. M-2138
Container 10.000 liters made of V2A, used, isolated, horizontal
EUR 7.200,00
add. 19 % VAT excl. shipping costs
Volume approx. 10,000.00 litres
Product description
Container 10.000 liters made of V2A, used, isolated consists of the material 1.4301(AISI304) V2A. The volume is approx. 10,000.00 litres. The diameter inside includes 2,000 mm. Container 10.000 liters made of V2A, used, isolated was last used in the following area: Foodstuffs. Delivery can take place worldwide.
This product is suitable for the following applications:
Storage, Hot water, Mixing, Cleaning/CIP,General
Volume approx.
10.000,00 litres
Structure
Horizontal
Condition
Used
Dimensions approx.
Internal diameter
2.000 mm
External diameter
2.100 mm
Cyl. length
3.200 mm
Foot height
600 mm
Total height
3.200 mm
Total length
3.800 mm
Design
Weight approx.
2.000,00 kg
Weight per unit volume approx.
1.000,00 kg/m³
Insulation
yes
Interior surface
Smoothed
Exterior surface
Marbled
Floor type
Conical bottom
Agitator
Agitator quantity
1 (piece)
Agitator type
Propeller
Agitator position
Head off-centre
Supports
Supports
Stainless steel feet
Number of feet
4 (piece)
Fixtures and fittings
Manway position
Front face
Nozzle connector
Screw thread
Outlet nozzle
50
Cleaning/CIP nozzle
in head
Technical documentation
Technical documentation
None
Other
Last usage
Foodstuffs
This product is suitable for use as:
Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Syrup tank, Molasses tank/liquid sugar tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, CIP tank, Hot water tank, Thermal buffer, Cold water tank,
Agriculture: Substrate tank, Rainwater tank, Slurry tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, CIP tank, Hot water tank,
Chemistry and pharmaceuticals : Chemical tank, Storage tank, Septic tank, Acid tank, Lye tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, Anaerobic digestion tank, CIP tank, Hot water tank, Thermal buffer, Cold water tank,
