Product no. M-2372
Container 12.000 liters made of V2A, standing
EUR 6.900,00
add. 19 % VAT excl. shipping costs
Volume approx. 12,000.00 litres
Product description
Container 12.000 liters made of V2A consists of the material 1.4301(AISI304) V2A. The volume is approx. 12,000.00 litres. Container 12.000 liters made of V2A was last used in the following area: Foodstuffs. Delivery can take place worldwide.
This product is suitable for the following applications:
Storage,General
Volume approx.
12.000,00 litres
Structure
Standing
Condition
Used
Dimensions approx.
External diameter
2.000 mm
Cyl. height
3.750 mm
Foot height
700 mm
Total height
4.850 mm
Design
Weight approx.
800,00 kg
Weight per unit volume approx.
1.000,00 kg/m³
Insulation
no
Interior surface
Smoothed
Exterior surface
Marbled
Floor type
Torispherical bottom
Head design
Torispherical bottom
Supports
Supports
Stainless steel feet
Number of feet
4 (piece)
Fixtures and fittings
Manway position
In shell
Nozzles/connectors in shell
2xDN40 1x2" (piece)
Nozzles/connectors in head
1xDN80 1xDN40 (piece)
Fixtures and fittings
Fill level pipes
Technical documentation
Technical documentation
None
Other
Last usage
Foodstuffs
This product is suitable for use as:
Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Fruit juice tank, Spirituous beverages tank, Storage tank, Buffer tank, Pre-buffer tank,
Agriculture: Storage tank, Buffer tank, Pre-buffer tank,
Chemistry and pharmaceuticals : Storage tank, Buffer tank, Pre-buffer tank,
